How to connect AWS Lambda to RDS Databases: A Practical Solution

Integrating AWS Lambda with Amazon RDS securely and efficiently poses significant challenges, particularly when managing connections from Lambda functions that operate outside a Virtual Private Cloud (VPC). This article explores various approaches to this problem, details the limitations of each, and ultimately describes a practical, innovative solution that optimizes both security and cost.

The Challenge

The challenge is to enable a Lambda function, which typically does not operate within your VPC, to interact securely with an Amazon RDS instance housed within your VPC. This needed to be accomplished without sacrificing the inherent benefits of serverless architectures such as scalability and cost-efficiency, while ensuring the database remained shielded from public internet access.

Exploring Initial Approaches

One straightforward approach was to directly attach the Lambda function to the VPC, anticipating easy access to the RDS instance. However, this method significantly increased cold start times and required costly additional components like NAT gateways for outbound internet access, making it less desirable.

Considering alternatives, we turned to AWS PrivateLink as a means to provide secure, private connectivity between the Lambda function and the RDS instance. Although PrivateLink effectively isolates data transfer from the public internet, its setup was complex and lacked flexibility, making it a cumbersome solution for our needs.

An alternative approach was to expose the RDS instance to the internet under stringent security measures. This method was quickly deemed too risky, potentially exposing sensitive data and complicating compliance with data protection regulations.

The Turn to Lambda-to-Lambda Invocation

After reassessing our needs and the available AWS services, we opted for a Lambda-to-Lambda invocation approach. This involved:

• Main Lambda Function: Handles all application logic except database interactions, operating outside the VPC.
• Sub Lambda Function: Located within the VPC, dedicated solely to secure database operations on the RDS instance. This function is invoked by the main Lambda as required.

Here’s how the main Lambda function might look, which invokes the sub Lambda function:

// Import the AWS SDK and instantiate the Lambda client
const { LambdaClient, InvokeCommand } = require("@aws-sdk/client-lambda");
const client = new LambdaClient({ region: "us-west-2" });

exports.handler = async (event) => {
    const params = {
        FunctionName: "SubLambdaFunctionARN",
        InvocationType: "RequestResponse",
        Payload: JSON.stringify({
            query: "SELECT * FROM your_table",
            parameters: event.parameters
        })
    };

    try {
        const data = await client.send(new InvokeCommand(params));
        console.log("Invocation successful:", data);
        return { statusCode: 200, body: JSON.stringify('Database operation initiated.') };
    } catch (err) {
        console.error("Invocation failed:", err);
        return { statusCode: 500, body: JSON.stringify('Failed to initiate database operation') };
    }
};

And here is the corresponding sub Lambda function, securely placed within the VPC, and performing the actual database operations:

const mysql = require('mysql2/promise');

const dbConfig = {
    host: 'rds-proxy-endpoint',
    user: 'username',
    password: 'password',
    database: 'dbname'
};

exports.handler = async (event) => {
    let connection;
    try {
        connection = await mysql.createConnection(dbConfig);
        const [rows, fields] = await connection.execute(event.query, event.parameters);
        console.log("Query executed successfully:", rows);
        return { statusCode: 200, body: JSON.stringify(rows) };
    } catch (error) {
        console.error("Error executing query:", error);
        return { statusCode: 500, body: JSON.stringify('Failed to execute query') };
    } finally {
        if (connection) {
            await connection.end();
        }
    }
};

Cost Comparison

Scenario: 1 million requests per month, with each request invoking the Lambda function for 500ms, and each Lambda function having a memory allocation of 512 MB.

To better understand the financial implications of each method, we’ve prepared a cost comparison based on typical usage scenarios:

1. Lambda Attached to VPC with NAT Gateway:

• Total Approximate Cost: ~$46.53 per month.

1. Lambda with PrivateLink:

• Total Approximate Cost: ~$8.48 per month.

1. Lambda-to-Lambda Invocation:

• Total Approximate Cost: ~$2.16 per month, not including any additional charges for data transfer within the AWS network.

Conclusion

Our exploration and eventual implementation of the Lambda-to-Lambda invocation model underscore the importance of flexibility and creativity in cloud architecture. This solution not only met our security and performance criteria but also aligned with our cost-efficiency goals. It serves as a robust blueprint for similar scenarios where secure, efficient, and cost-effective serverless database interactions are required.

Reflection

For teams facing similar integration challenges, this solution illustrates that thinking beyond conventional configurations can lead to more effective solutions. As serverless computing continues to evolve, adopting such innovative approaches will be crucial for leveraging cloud capabilities fully while maintaining strict security and budget control. This case study exemplifies strategic problem-solving that could benefit any organization looking to optimize their cloud-based applications.
